- Keyboard
- Keyboard
- 61 keys (with velocity)
- Sound Generator
- Parts
- 8
- Tones
- 1,600 tones or greater
55 Drum kits or greater - Expansion
- EXZ World Expansion Series
* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the internal memory.
Maximum number of Expansions: 3
* Depends on size of Expansion titles - Sample Import
- Audio file: WAV
File format: 44.1/48 kHz, 16/24 bits
Approximately 12 minutes of samples can be used in total.
Up to 3 minutes of stereo per sample (44.1 kHz, 16 bits)
* Share with Expansion titles - Preset Scene
- 1,600 scenes or greater
- User Scene
- 256
- Scene Remain
- Yes
- Favorite
- 100
- Effects
- Multi-Effects: 8 systems, 93 types
Part EQ: 8 systems
Drum Part COMP: 6 systems
Insertion Effect: 1 system, 93 types
Chorus: 10 types
Reverb: 8 types
System EQ: 1 system - Step Sequencer
- Step Sequencer
- 8 Tracks (per scene)
Maximum 64 steps
Recording Method: Realtime recording, Step recording, TR-REC
Editing Method: Step edit - Audio File Player Section
- Audio File Player Section
- Audio file: WAV, AIFF
File format: 44.1/48 kHz, 8/16/24 bits
Speed/Pitch Control: Yes - Other
- Rhythm pattern
- Yes
- Arpeggio
- Yes
- Chord Memory
- Yes
- Controllers
- Pitch Bend/Modulation lever
Slider x 4
2 x 4 Pads - Display
- Graphic LCD (128 x 64 dots with backlight)
- Connectors
- PHONES jack: Stereo miniature phone type
OUTPUT jacks (L/MONO, R): 1/4-inch phone type
PEDAL jack
USB MEMORY/EXT DEVICE port: Type-A (Storage, MIDI)
USB COMPUTER port: USB Type-C(R) (Class Compliant for Audio and MIDI/ Roland driver for Audio and MIDI) - External Memory
- USB flash drive (sold separately)
- Power Supply
- AC Adaptor
USB bus power supply (USB Type-C(R) port)
* External power supply from a USB Type-A port isn't available. - Current draw
- 500 mA (AC adaptor)
1,400 mA (USB bus power supply) - Power consumption when in OFF mode (when the power automatically turns off)
- 0.2 W
- Accessories
- Startup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-5U)
Power cord - Options (sold separately)
- Keyboard Stand: KS-11Z, KS-13
Pedal Switch: DP-2, DP-10
Expression Pedal: EV-5 - Size and Weight
- Width
- 1,002 mm
39-1/2 inches - Depth
- 268 mm
10-9/16 inches - Height
- 93 mm
3-11/16 inches - Weight
- 4.6 kg
10 lbs 3 oz
